Alpine iLX-F903T6 - 1-DIN Autoradio

ILX-F903T6 - The upgrade for your Volkswagen T5 / T6

Car stereo for VW T5 and T6 with 9-inch touch screen 1-DIN chassis, DAB +, Apple CarPlay and Android Auto support

• The Alpine Halo9 iLX-F903T6 with 9-inch touch screen and high resolution is ideal for your on your Volkswagen T5 (7H / E / J) model year 09/2009 - 06/2015 and T6 (7H / E / J) from model year 07 / 2016 adapted and agreed.
• With this fantastic product, you get Apple CarPlay and Android Auto, online navigation features, DAB + digital radio, USB video playback, Bluetooth hands-free and audio streaming, and more.
• High-end sound quality and tons of sound tuning options complete the system's extensive equipment list.

EQUIPMENT
tuner

• Station memory: FM: 12 / MW: 6 / LW: 6
• Station memory: Automatic station memory
• Search function: Manual / Local / DX selection

RDS

• RDS functions: PI, PS, AF, TA, TP, PTY, NEWS, RADIO TEXT

DAB + tuner

• Integrated DAB + tuner
• DAB + / DMB support
• DAB + Slideshow Service
• DLS (Dynamic Label Service)
• DAB + to DAB + Service Following
• FM linking (automatic DAB + / FM switching (if signal available)
• Station memory: 18 program memory slots
• Automatic ensemble / service storage
• Alphabetic station search function
• PTY search function
• Service search function
• Phantom power for DAB antenna selectable (on / off)

BLUETOOTH

• Integrated BLUETOOTH module
• Wide Band Speech Technology
• Handsfree: HFP (Hands Free Profile) compatible
• Music Streaming: A2DP (Advanced Audio Distribution Profile) compatible
• Music Streaming Control: AVRCP (Audio / Video Remote Control Profile) Version 1.5 compatible
• Advanced BLUETOOTH technology
• Connection: SSP (Secure Simple Pairing) support
• Individual profile connection: handsfree and music streaming
• Phonebook: Automatic phonebook transfer
• Direct dial keys: 4 memory slots per telephone
• Registration of different phones: 5 different phones can be registered
• Multiple numbers: up to 5 phone numbers per contact can be displayed
• Device name Display
• Automatic call acceptance
• Call list: dialed number / calls received / missed calls
• Redial function
• Voice volume setting: Adjustable for incoming and outgoing calls
• DTMF tone function
• Display of GSM signal strength
• Display of the battery charge state
• Menu Language selection: 24 menu languages
• Firmware Updatbar
• Including microphones

Made for iPod / iPhone

• Compatible with iPod / iPhone: Made for iPod Touch 6th / 5th Gen, iPod nano 7th Gen, iPhone X, iPhone 8 and 8 Plus, iPhone 7 and 7 Plus, iPhone 6 and 6 Plus, iPhone 5S, iPhone 5C, iPhone 5, iPhone 4s
• Connection: KCU-471i required (optional)
• Possible choices: Playlist, Artist, Album, Song, Podcast, Genre, Composer, Audiobook
• Alphabetical search
• Album cover ad
• Direct Up / Down: Playlist / Artist / Album / Genre / Composer
• MIX (Shuffle) Play: Song, Album, All
• repeat
• charging

connectivity

• Works with Apple CarPlay (CarPlay enabled smartphone required)
• Works with Android Auto (Android Auto enabled smartphone required)

Online navigation functions

• Online navigation in conjunction with Apple CarPlay and Android Auto
• Including GPS / Glonass antenna
• Dirketer access to the navigation of CarPlay or Google Maps

USB port

• USB port on the back
• Music playback formats: FLAC / MP3 / WMA / AAC
• Video playback: MP4 compatible
• File / Folder name search
• Tag Info Search
• Folder Up / Down
• MIX random play
• repeat

Sound tuning

• BASS ENGINE  Pro
• BASS ENGINE SQ
• Subwoofer level adjustable
• Subwoofer phase selectable
• 4 V preamp output
• Equalizer: Flat, Pop, Rock, News, Jazz, Electrical Dance, Hip Hop, Easy Listening, Country, Classical
• Dual HD EQ (9-Band Parametric Equalizer (Front / Rear Separated))
• 6-channel time correction
• Digital crossover
• Customizable sound settings by vehicle type
• MediaXpander HD
• Source volume customizable
• Download online sound settings
• Easy, step-by-step sound adjustment
• "Alpine TuneIt App" readout

General

• Output power: Max. Power 4x 50 W high power amplifier
• Integrated premium quality amplifier for excellent sound
• Display: 9-inch capacitive WVGA high resolution display
• White LED backlight
• Touch screen with slide function / pull and scroll function
• Customizable favorites screen
• 2 user profiles can be created
• High quality audiophile design
• Preamp: 3 PreOuts (4V, Front / Rear / Subwoofer)
• AUX-In: 1x A / V input (3.5 mm jack connection)
• Suitable for steering wheel remote control
• Vehicle Display Interface Ready (UART connector)
• Navigation Mix Announcement
• Camera connection for RCA input
• Rear view camera guide lines
• Rear view camera with immediate start function (immediate display of rear view camera at system start)
• Simple Mode & Info Mode Display
• Visual EQ
• Live contrast adjustment
• Menu language: 24 languages ​​(for AV & Bluetooth)
• time of day
• Automatic dimmer
• Anti-theft device with numeric code
• Firmware updatebar
• Antenna Control Remote (On / Off)
• Remote turn-on
• HDMI input (special Alpine HDMI connection cable required)
• Start-Stop Ready

Mounting material for VW T5 facelift and T6

• Compatible with VW T5 Facelift and T6: Multivan, Caravelle, California, Van and Van Van (7EA / B / F / H / J, 7HA / B / F / H / J / M / N, 7JB / E / L / Y / Z).
• Steering wheel remote control interface with CAN-analogue conversion, MFA support and comfort function display (HVAC - Heating & Air Conditioning, OPS - optical parking sensor) and SIRI support

SPECIFICATIONS

screen

• Screen size: 23 cm (9-inch) capacitive WVGA display
• LCD Type: Transparent Type TN LCD
• Workstation: TFT Active Matrix
• Number of pixels: 1,152,000 pixels (800 x 480 x 3)
• Lighting system: White LED backlight
• Effective number of pixels: 99.99% or more
• Color system: NTSC, PAL

Maximum output power

• Max Power Output: 4 x 50W

FM tuner

• Frequency range: 87.5 - 108.0 MHz
• Mono usage sensitivity: 8.1 dBf (0.7 μV / 75 ohms)
• 50 dB sensitivity: 12 dBf (1.1 μV / 75 ohms)
• Alternative channel selectivity: 80 dB
• Signal-to-noise ratio (S / N): 65 dB
• Stereo channel separation: 35 dB
• Simultaneous wave fluctuation: 2 dB

MW tuner

• Frequency range: 531 - 1.602 kHz
• Sensitivity (IEC standard): 25.1 μV / 28 dBf

LW Tuner

• Frequency range: 153 - 281 kHz
• Sensitivity (IEC standard): 31.6 μV / 30 dBf

USB

• USB requirements: USB 2.0
• Max. Current consumption: 1,500 mA (CDP support)
• USB class: playback from the device / mass storage
• File system: FAT 16/32
• MP3 decoding: MPEG-1/2 AUDIO Layer-3
• WMA decoding: Windows Media ™ audio
• AAC decoding: ACC-LC format '' .m4a '' file
• Flac-decoding: Free Lossless Audio Codec flac / fla
• Number of channels: 2-channel (stereo)
• Frequency response: 5 - 20 kHz ± 1 dB * J e according Encodingsoftware and bit rate
• Total Harmonic Distortion - THD (at 1 kHz): 0.008%
• Dynamic range (at 1 kHz): 95 dB
• Signal-to-noise ratio: 100 dB
• Channel separation (at 1 kHz): 85 dB

GPS / Glonass

• GPS / Glonass compatible antenna included

BLUETOOTH

• BLUETOOTH  Version: Bluetooth V3.0
• Output power: +4 dBm max. (Performance class 2)
• HFP (Hands Free Profile)
• OPP (Object Push Profile)
• PBAP (Phone Book Access Profile)
• A2DP: (Advanced Audio Distribution Profile)
• AVRCP: (Audio / Video Remote Control Profile)
• SPP (Serial Port Profile)

Sound tuning

• Subwoofer Level adjustable: 0 to +15
• Subwoofer phase: 0 ° or 180 °
• BASS ENGINE SQ: 5 modes, level 0 to +6
• High pass filter (frequency): 20/25 / 31.5 / 40/50/63/80/100/125/160/200 Hz
• High Pass Filter (Slope): Off / -6 / -12 / -18 / -24 dB / Oct.
• High pass filter (gain): -12 to 0 dB
• Low Pass Filter (Frequency): 20/25 / 31.5 / 40/50/63/80/100/125/160/200 Hz
• Low Pass Filter (Slope): Off / -6 / -12 / -18 / -24 dB / Oct.
• Low pass filter (gain): -12 to 0 dB
• Runtime correction: 0.0 to 336.6 cm (3.4 cm increments) or 0.0 - 9.9 ms (0.1 ms increments)
• Dual HD EQ - 9 Band Parametric Equalizer for Front + Rear
• Parametric equalizer (Band 1): 20 - 100 Hz
• Parametric equalizer (Band 2): 63 - 315 Hz
• Parametric equalizer (Band 3): 125 - 500 Hz
• Parametric equalizer (Band 4): 250 - 1k Hz
• Parametric equalizer (Band 5): 500 - 2k Hz
• Parametric equalizer (Band 6): 1k - 4k Hz
• Parametric Equalizer (Band 7): 2k - 7.2k Hz
• Parametric Equalizer (Band 8): 5.8k - 12k Hz
• Parametric Equalizer (Band 9): 9k - 20k Hz
• Parametric equalizer (gain): ± 14
• Parametric equalizer (bandwidth): 1, 2, 3
• Source volume: ± 14

HDMI

• Input format 480p / VGA

General

• Power supply: 14.4 V.DC (11-16 V permitted)
• Pre-amp output (without clipping): 4 V / 10 kOhm
• Maximum installation angle (black box): 30 ° to the horizontal

Dimensions

• DIN dimensions: 1-DIN housing and 9-inch capacitive touchscreen
• Case dimensions (W x H x D) mm: 178 x 50 x 160 mm
• Monitor dimensions (W x H x D) mm: 235.2 x 152.2 x 19 mm

Compatible vehicles

• Volkswagen T5 Facelift (7 H / E / Y) model year: 09/2009 - 06/2015
• Volkswagen T6 (7 H / E / Y) model year: 07/2016 →

Small changes on the dashboard necessary.
