Rockford Fosgate Marine PMX-0 - Digital Media Receiver

PMX-0 - Punch Marine Ultra Compact Digital Media Receiver

The ultra-compact digital media receiver PMX-0 is IPX6-certified and uses a waterproof rotary knob with white LED button illumination and front-mounted under-level controls. It offers Bluetooth audio streaming for Apple and Android products as well as additional audio input and is the ideal choice for this small system media receiver.

The PMX-0 is an ultra-compact digital media receiver developed from the ground up, which is ideal for small systems and vehicles. This device has Bluetooth audio streaming connectivity for Apple and Android based devices, RCA AUX inputs, and front, rear and sub RCA output connections. It is controlled via the waterproof rotary knob and the white LED buttons with backlighting and enables immediate control below the level.

The front panel is IPX6 certified for the ingress of water spray and has a conformal coated circuit board that protects the vital electronics. We validate the device with 500 hours of testing according to ASTM B117 and D4329 test standards to ensure that it can withstand years of daily use exposed to the elements.

• Bluetooth Streaming Audio (A2DP) protocol version 1.0 installed
• Simple Secure Pairing (SSP)
• Waterproof speed control
• White LED key illumination
• Front control sub control
• Voice command confirmation
• AUX-In rear (L / R)
• Rear USB with 1A charge only
• Epoxy coated circuit board for water resistance
• Updatable firmware and bluetooth software via USB
• Easy 2 "mounting hole and compression U-clamp assembly

Specifications

• Device type: Ultra compact digital media receiver
• Bluetooth: 3.0, AVRCP & A2DP
• AUX input: 1 x RCA stereo
• Dimensions W / H / D: 10.41 cm / 6.6 cm / 3.35 cm / face depth: 3.8 cm / chassis depth: 2.54 cm / mounting opening: 5.2 cm
• Operating voltage: 10.5 V - 16 V.
• Fuse rating: 3 A
• USB output current: 1 A (charging only)
• Android Compatibility: Bluetooth only
• iPod Compatibility: Bluetooth only
• iPhone Compatibility: Bluetooth only
