Ampire OHV156-HD - 39.6cm (15.6'') Full HD ceiling monitor with HDMI input

Ampire OHV156-HD - 39.6cm (15.6'') Full HD ceiling monitor with HDMI input

The new OHV156-HD monitor from AMPIRE is an ultra-flat HD monitor with a height of just 30mm. It has an HDMI and video input. You can also play various video, audio and image formats via the USB interface. All connections are not located on the housing, but are routed out as a cable harness on the bottom of the device. This enables a professional and long-lasting installation with invisible cabling.

Equipment

• Integrated lighting via 8 LEDs (can be switched off)
• Integrated blue ambient lighting (can be switched off)
• Control buttons with blue night lighting
• Infrared remote control

Video

• Inputs: HDMI, AV (Cinch), USB (all connections on the back of the device on the cable harness)
• AV video output via Cinch, but only if the AV video input has been selected (not for HDMI and USB)

Audio

• Audio output in stereo via Cinch. We recommend connecting this output either to the AUDIO AUX of your car radio or with optional wireless headphones.
• Infrared transmitter for optional wireless headphones (item number: HP301) with two adjustable infrared channels: A (2.8MHz + 2.3MHz.) or B (3.8MHz + 3.2MHz.)
• With the integrated FM transmitter you can play the sound as an FM radio station via the car radio. The following FM frequencies can be set: 87.7, 87.9, 88.0, 88.1, 88.2, 88.3, 88.4, 88.5 and 88.6 MHz. We recommend using the FM transmitter for sound transmission only as an emergency solution. Because the limited sound quality of the FM is not high quality.

USB input

• Video: MPEG1/2/4, RM, RMVB, MOV, D I V X, MJPEG
• Audio: WMA, MP3, M4A, AAC
• Images: BMP, JPEG, GIF, PNG, TIFF
• Supports USB 2.0 sticks

LCD display

• Screen diagonal: 39.6cm (15.6")
• AUO High Definition LCD digital panel
• LED backlight
• Resolution: 1920 x 3 (RGB) x 1080 pixels
• Brightness: >300 nits
• Contrast: >500:1
• horizontal viewing angle: 140°
• vertical viewing angle: 120°
• 262,144 / 16,777,216 colors (18-bit / 24-bit)
• Video standard: PAL/NTSC
• Image format switching 16:9 and 4:3
• Our monitors are subject to ISO 9241-307, pixel error class II

Installation instructions

When installing the monitor, please note that the supplied mounting plate must be installed. If the mounting plate is missing, the housing of the monitor could warp and other problems could occur.

More Data

• Operating voltage: 11-14 Volt DC
• Current consumption: 1.78A
• Standby current with ignition switched on: 0.04A
• Standby current with ignition switched off: 0.00A
• Operating temperature: -10°C to +70°C
• Dimensions of monitor closed: 410x320x30mm
• Dimensions of monitor opened: 410x320x260mm
• Opening angle of monitor: 180°
• Weight: 2.9kg
• 2.25 meter connection cable

Packaging

• Shipping weight: 3.5kg
• Dimensions of device box: 537x74x428mm

Approval

• CE approval, Report No. BST16087768A0001Y-1ER-1
• REACH approval, Report No. BST16087768A0001Y-1RR4
• E11 10R 023588
