Rockford Fosgate Marine M2-TS - 25mm Hochtöner

The compact digital media receiver PMX-2 was developed for marine and motorsport applications.

The PMX-2 has a 6.85 cm full color TFT display for optimal visibility - even in full sun - which is optically wet glued to prevent the ingress of dust or moisture. It is IPX6 certified and uses a waterproof rotary encoder knob with white LED button illumination and front-mounted sub-level controls. With functions such as Pandora control functions and Bluetooth audio steaming with support for album art1, this device becomes a real command center for any system.

Output flexibility comes with an internal amplifier of 4 x 50W @ 2 ohms or RCA front and rear / sub output RCA amplifiers that allow after-market amplifiers to be added for more power and performance When you add the EEPROM storage system, custom GUI interface and wired remote expansion capabilities, you have the only media receiver you will ever need.

• ISO8846 / SAE J1171 ignition protection certified
• Pandora Internet Radio
• A2DP and AVRCP Bluetooth wireless streaming
• FCC, CE, IC and C-Tick certified
• Radio frequencies for several regions
• Low voltage warning
• AUX and USB inputs with USB charging
• On board punch EQ control
• iPod playback with on-screen display
• Independent subwoofer volume control
• Selectable HP / LP / AP crossovers with selectable slope 12/24 dB / oct.
• IPX6 marine grade
• 7-band graphic EQ
• 2.8 "/ 6.85 cm full color display with automatically dimming background lighting
• AM / FM / WB tuner
• Zone control: 1 zone / 1 source (F / R or Sub)

* Antenna not included

Specifications

• Device type: Compact digital media receiver with display and 4-channel amplifier
• Screen size: 6.85 cm color TFT
• Dimensions W / H / D:    11.5 cm / 10.6 cm / 7.4 cm - face depth: 3.8 cm - mounting opening: 7.7 cm
• Operating voltage: 10.5V - 16V
• Fuse rating: 20A
• Clock: N / A
• Pandora Web Radio
• SiriusXM-Ready: N / A
• Bluetooth: 3.0 + EDR, A2DP 1.3
• Apple / Android compatible
• Multi-Zone / Multi-Source: N / A
• AUX input: 1x RCA stereo
• USB charging
• Speaker outputs
• Steering wheel controls ready: N / A
• Power: CEA-2006 nominal power 25 W x 4 at 4 ohms RMS - 50 W x 4 at 2 ohms peak ≤ 1.0% THD + N
• Speaker Outputs: Front and Rear, 2 Ohm - Front Line Out - Rear or Sub Line Out
• Cinch output voltage: 4 V.
• RCA output impedance: 500 ohms
• Frequency response: 20 Hz - 20 kHz
• Presets: 18 FM / 12 AM / 6 WB
• Frequency range of the FM tuner: 87.5 MHz - 107.9 MHz
• FM tuner sensitivity: 8 dB
• AM tuner frequency range: 530 kHz - 1710 kHz
• AM tuner sensitivity: 40 dB
• Frequency range of the web tuner: 162.40 - 162.55 (USA & Canada)
• Media Player Audio Format: MP3, WMA, FLAC
• Video input: N / A

Compatible with

• PMX-1R
• PMX-0R (3 remote limiters, 30 m total cable distance)

USB version: 2.0

• USB capacity: 32 GB max. / 999 folders max. / 999 songs max.
• USB output current: 1A

Android compatibility

• Bluetooth only

iPod compatibility

• iPod Touch (5th generation)
• iPod Touch (4th generation)
• iPod Nano (7th generation)
• iPod Nano (6th generation)

iPhone compatibility

• iPhone XS (pending)
• iPhone XS max
• iPhone XR (pending)
• iPhone X.
• iPhone 8
• iPhone 8 Plus
• iPhone 7
• iPhone 7 Plus
• iPhone 6s
• iPhone 6s Plus
• iPhone 6
• iPhone 6 Plus
• iPhone 5s
• IPhone 5c
• iPhone 5
• iPhone 4
• iPhone 4s
• 3GS phone
