ESX QL500.1 - 1-Channel Digital Amplifier

QUANTUM QL AMPLIFIER

The brand new QUANTUM QL amplifiers in the ESX portfolio are technically the little siblings of the QE models. They are ideal for use where the installation space is very tight. They are also emission-free and, like the large QE models, have the finest Class D technology on board, which leaves nothing to be desired in terms of performance, sound quality and setting options. The QL models share the optics and dimensions with the XE-DSP amps and the X-DSP processor, so that high-quality DSP systems with a lot of power can be built up by combining the devices. The space-saving remote control is also included with the QL models.

• Advanced class D technology with very high efficiency
• Selected and audiophile-coordinated components
• Solid aluminum heat sink
• Heavy side parts made of cast aluminum
• High level inputs with Error Protection System
• Auto turn-on, start / stop ready
• MOSFET-PWM power supply, 3-way protection circuit
• Compact bass cable remote control

QL500.1 - Mono Class D digital amplifier

• 500 watts RMS output power
• 1 x 300/500 watt RMS at 4/2 Ohm
• Subsonic 10-40 Hz, LP 40-150 Hz
• Bass boost 0-18 dB, phase shift 0-180 °
• High level inputs, automatic switch-on function
• Compact cable remote control for bass levels
• Dimensions: 226 x 43 x 120 mm
• Efficiency up to 93%
