RetroSound MOTOR-6DAB - Radiomodul für viele Modelle

The article "MOTOR-6" is the radio module for the models "San Diego", "Huntington", "Wonderbar" and "Monterey" with all cables and accessories but without the display unit. The display unit, the control knobs and the rear control rings must be ordered separately.

It has a Bluetooth handsfree, A2DP audio streaming and Apple iPod / iPhone control. The touchscreen operation of the Apple iPod / iPhone is still active in parallel. Of course, the "MOTOR-6" radio module also has the flexible "InfiniMount" mounting system and control knob patented by RetroSound. With this device, you get the design of your classic and do not have to do without modern digital media. Two USB and two AUX inputs on the back panel allow you to play external MP3 players, such as an iPod or DAB + receiver.

Any concerns that your H license plate might be at risk due to the installation of a RetroSound car radio are unfounded. In the download you will find a confirmation with the approval of the entire AKE working group (TÜV SÜD, TÜV Rheinland, TÜV Nord, Dekra, KÜS, GTÜ) stating that the Retro Sound Model Zuma "and the Retro Sound Model Two" including vehicle-specific aperture and control knobs may be installed in vintage cars with H license plate or not prevent the award of the H license plate!

domestic equipments

• Playback of MP3 and WMA files via the rear USB input
• Apple iPod / iPhone control (touchscreen operation of the Apple iPod / iPhone is still active in parallel)
• Bluetooth handsfree with A2DP audio streaming
• Adjustable LCD lighting with 32,000 different colors
• DAB + / FM / MW radio receiver with RDS and 30 stations memory
• Tuner with European even and odd radio frequencies
• Integrated 4-channel amplifier (4 x 24 watts RMS / 45 watts max.)
• 3 stereo RCA outputs for external amplifiers (front / rear / subwoofer)
• 2 years manufacturer warranty
• 3 equalizer programs plus individual bass / treble / fader / balance adjustment
• E-approval e13 03 10006 e13 * 72/245 * 2006/96 * 10006 * 00
• XBAS loudness function
• Auto reset to factory settings when 5 minutes de-energized

expansion options

• 2 USB inputs (rear panel)
• 2 AUX inputs (stereo)
• 3 RCA outputs (stereo) for external amplifiers (front / rear / subwoofer)
• Separate switch-on line for motor antenna and amplifier

Technical specifications

FM

• European broadcasting frequency range with RDS 87.5-107.9
• Antenna external connection
• Sensitivity 12.5 dBf
• Transmitter separation 75 dB at 400 KHz
• Signal to noise ratio 62 dB
• Distortion at 1 kHz 0.8% (stereo) 0.5% (mono)
• Channel separation 32 dB at 1 kHz
• Frequency response 30-16000 Hz

MW

• Frequency range 530-1710 kHz
• Antenna external connection

IPod / IPhone compatibility

• iPhone 7 Plus (IP400L cable required)
• iPhone 7 (IP400L cable required)
• iPhone 6 Plus (IP400L cable required)
• iPhone 6 (IP400L cable required)
• iPhone 5 (IP400L cable required)
• iPhone 4s (IP400 cable required)
• iPhone 4 (IP400 cable required)
• iPhone 3GS (IP400 cable required)
• iPhone 3G - iPod touch 4G (IP400 cable required)
• iPod touch 3G (IP400 cable required)
• iPod touch 2G (IP400 cable required)
• iPod nano 6G (IP400 cable required)
• iPod nano 5G (IP400 cable required)
• iPod nano 4G (IP400 cable required)
• iPod nano 3G (IP400 cable required)
• iPod classic 160GB (IP400 cable required)
• iPod classic 12GB (IP400 cable required)
• iPod classic 80GB (IP400 cable required)

General data

• Dimensions radio base 101x51x136mm
• Power supply 10.5 to 14.4 volts
• Maximum current consumption 15 amps
• Quiescent current 3.5 mA
• Output 12V, 4 ohms, <1% distortion:4x15 watts sine wave
• Impedance speaker 4-8 ohms
• RCA outputs 6 channel 2.85 volts for external amplifiers (front / rear / subwoofer)
• Input sensitivity AUX1> 300 mV / 6 kOhm
• Input sensitivity AUX2> 300 mV / 6 kOhm

Legal notice
iPod and iPhone are trademarks of APPLE Computer, registered in the US and other countries.
For best results, Apple has created specific compatibility requirements for accessory manufacturers.
Products that are designed and certified to be compatible have the "Made for" label on the packaging.
To ensure compatibility when purchasing third-party accessories for use with your device, look for "Made for" accessories for your device (see below).
"Made for iPod" means that an electronic accessory is specifically designed to be connected to the iPod and has been certified by the developer to meet Apple performance standards.
"Made for iPhone" means that an electronic accessory is specifically designed to be connected to the iPhone and has been certified by the developer to meet Apple performance standards.

E-registration
E-approval e13 03 10006 e13 * 72/245 * 2006/96 * 10006 * 00

Vehicles with 6 volt electrical system

You need a voltage converter if you want to operate a RetroSound car radio in a vehicle with 6 volt electrical system.
We recommend the DC / DC converter 2238.0 from Statron (www.statron.de) in such a case.

*Important NOTE
Please order the display unit "Huntington" and control knobs for your car separately. This is not included with the car radio.

Compatible display units

• FACE-LB-C
• FACE-LB-B
• FACE-LB-BC
• FACE-LB-CB
• FACE-LB IVO
• HUNTINGTON
• M2B-FACE
• M2C-FACE
• M2BC-FACE
• M2CB-FACE
• M2I-FACE
